The 4.5 ton diesel forklift truck provides a range of options to suit your specific needs. Originally equipped with robust and reliable Chinese engines known for their powerful performance, there are also various imported engines available.

Safety is top priority with a specially crafted solid overhead guard, providing this small diesel forklift an additional layer of security for operators navigating various work environments.

The easily noticeable warning light on this outdoor forklift is designed to capture the attention of pedestrians, effectively reducing potential risks.

The strategically positioned air intake system, installed at a high level, ensures complete protection for the forklift's engine, guaranteeing reliable performance during long and challenging operations.

The seat design of the 4.5 ton diesel forklift truck takes full consideration of ergonomic principles, which not only maximizes operating comfort but also reduces fatigue caused by long-term continuous operation.

Technical Specification

Model		FD45
Rated lifting load	kg	4500
Load center distance	mm	500
Free lifting height	mm	160
overall length (With fork/Without fork)	mm	4120/3050
Width	mm	1400
Overhead guard height	mm	2230
Wheelbase	mm	1900
Minimum ground clearance	mm	150
Mast tilt angle (front/rear)	%	6° /12°
Tire no. (before)		300-15-20PR
Tire no. (after)		7.00-12-12PR
Minimum turning radius (outer side)	mm	2820
Minimum right angle aisle width	mm	4830
Fork size	mm	107015050
maximum working speed(Full-load/No-load)	km/h	18/19
maximum lifting speed(Full-load/No-load)	mm/s	420/460
maximum gradeability(Full-load/No-load)	%	15/20
Forklift weight	kg	5860
Engine model		Quanchai4C4-50V31

attachment

diesel fork truck side shift

details

diesel lift truck detail

OEM

forklift diesel OEM customized

FAQ

Q: Are you a manufacturer, trading company, or a third party?

We are a manufacturer, and we have built our company since 2001. We have been in the construction machinery and material handling equipment industry for 22 years.

Q: What is your minimum order quantity, and can you send me samples?

Our minimum quantity is 1 set. As our product is machinery equipment, it's difficult to send you samples. However, we can send you a catalog and warmly welcome you to visit our company.

Q: What is the delivery time of your machine?

A: In general, the delivery time of our machine is about 30 days. Customized machines will be delivered based on negotiations with our clients.

Q: Can you produce the products labeled with the client's brand?

With the authorization of the brand, we can OEM for our clients.
