12 Ton High Capacity Electric Forklift

Items: 12 Ton Electric Fork Truck
Power type: electric
Rated capacity: 12000kg
Lifting height: 3000mm
Send Inquiry
Chat Now

Product Introduction

Products Detail



12 ton high capacity electric forklift is equipped with a renowned brand's imported controller for unparalleled performance. Meticulously designed and professionally tuned, this forklift guarantees exceptional precision and efficiency in both maneuvering and lifting operations. Boasting features such as regenerative braking, slope control, and self-diagnostic capabilities, it sets a new standard in the realm of industrial electric forklifts.

The full-visibility mast, optimized for enhanced visibility, features dual pipelines on both sides, offering drivers an outstanding forward view. Innovatively designed with a dual-battery layout in the central chassis, it provides an excellent rearward perspective for operators, ensuring safety and control in all directions.

Powered by an advanced dual-motor drive and dual-pump power system, the large electric forklift's compact structure delivers superior driving and climbing capabilities. With increased torque and robust output, it excels in performance, making it an ideal choice for demanding industrial environments.

The ergonomic driver layout of the battery forklift is tailored to human factors, creating a comfortable and convenient operational experience. The intuitive design enhances operator efficiency and minimizes fatigue, ensuring optimal productivity during extended use.

Ease of maintenance is a key highlight, featuring two sets of high-capacity batteries with an automatic replenishment system. The side-mounted battery layout simplifies replacement procedures, offering a straightforward, convenient, and secure process. The 12 Ton high capacity electric forklift's entire cabin can tilt backward, facilitating hassle-free maintenance and servicing.



full electric forklift
portable electric forklift

all terrain electric forklift

Products parameter
Model   FB120
Rated Capacity kg 12000
Load Centre mm 600
Lift Height mm 3000
Fork Size (L×W×T)  mm 1220×175×85
Mast Tilt Angle F/R (α°/β°) Deg 6/10
Length to face of fork (Without fork) mm 4415
Overall Width mm 2250
 Mast Lowered Height mm 2830
 Mast Extended Height (With backrest) mm 4260
Overhead Guard Height mm 2640
Turning Radius (outside) mm 3850
Front Overhang (Wheel center to fork face) mm 845
Tread (Front/Rear) mm 1736/1754
Ground Clearance (Bottom of mast) mm 230
Wheelbase mm 2850
Fork Spread (Min./Max) mm 515/2055
Travel Speed   km/h 14
Lifting Speed  (Full load) mm/s 280
 Max. Gradeability % 10
Service Weight kg 15800
 Front Tire   9.00-20
Rear Tire   8.25-20
Driven Motor kw 14×2
Lift  Motor kw 25×2
Battery Standard V/Ah 96/1250
Controller Manufacturer   CURTIS AC
Operating Pressure for Attachment Mpa 18



Products image



LTMG's 12-ton electric forklift is known for its low noise, zero emissions and low energy consumption, meeting environmental requirements. Equipped with a large-capacity battery and designed for heavy-duty operations, it ensures efficient performance. The stable four-point support further enhances its operation, making it an exceptional choice for environmentally conscious and productive manufacture.



image of electric warehouse forklift

certificates



LTMG concentrates on delivering top-notch, dependable products to our valued customers. With an impressive array of certifications such as ISO, CE, EPA, COC, COR, SABER, and CO, we showcase our dedication to being a trusted and conscientious leader in the industry. By upholding the highest standards of excellence, LTMG instills confidence in our customers, making us their preferred choice and trusted partner.



certificates of electric fork truck

Purchase process



LTMG ensures that your shopping process is efficient and comprehensive. Our professional and dedicated team guides you through every step, ensuring a seamless shopping experience for you.



purchase process of battery operated forklif



FAQ

Q: Are you manufacturer or trade company?

A:We are manufacturer and there are factories in Shandong, Fujian and Anhui province.

Q: How does LTMG manage product delivery, and what is the standard lead time for orders?

A: At LTMG, ensuring prompt delivery is a top priority. We boast a well-organized logistics network that guarantees both efficiency and the secure shipment of our products. While lead times may fluctuate depending on order details and destination, our team is dedicated to transparent communication and adhering to mutually agreed-upon delivery schedules.

Q: How can I address equipment issues during use?

A: If you encounter any problems, kindly email us with detailed descriptions and, if possible, include pictures or a brief video for a more comprehensive understanding. Our team will promptly assess and identify the issue, working towards a resolution.

Q: What is your main market?

A: LTMG has sold the products to Europe, North America, South America, Australia, The Middle East, and etc.
