Name: 2 Ton Electric Forklift
Brand: LTMG
SKU: 221065080

Products Description

The 2 ton electric forklift is versatile and efficient for your warehouse, factory, or other industrial setting. With its powerful and reliable performance, reliability, and ease of use, the small electric forklift is the perfect solution for all your heavy lifting and material handling needs.

small electric forklift

- Ergonomic operator compartment, with adjustable seat and steering column, provides maximum comfort and control

- Reliable, high-performance drive axle system from Linde, ensures optimal traction and stability in all working conditions

- Safety features such as an emergency stop button, warning alarms, and a rearview camera, ensure maximum safety of both the operator and the load

- Efficient AC motor, with advanced electronic control system, ensures smooth and precise operation

- Maintenance-friendly design, with easy access to all key components and service points

- High maneuverability and productivity, with fast travel and lift speeds, and excellent turning radius

- Energy-efficient and low maintenance, with long battery life and minimal service requirements

- User-friendly and easy to operate, even for novice operators

- Cost-effective and reliable, with a proven track record of performance and durability

electric forklift truck 1

The 2-ton electric forklift is a versatile and reliable solution for a wide range of material handling applications. With the battery forklift's advanced features, user-friendly design, and strong performance, it offers an unbeatable value proposition.

Specification

Model		FB20
Operation type	Drive in seat
Load capacity	kg	2000
Load center	mm	500
Power type	Electric
TIRE/CHASSIS
Tire type,driving wheel/load wheel	Pneumatic tyre
Number of wheels X=driving wheel (front/behind)	2X/2
Tire size (front/behind)	6.50-10-12PR/5.00-8-8PR 7.00-12-12PR/18X7-8PR 28x9-15-12PR/18x7-8-14PR
Service brake	Hydraumatic pedal
Parking brake	Mechanical manual
SIZE
Mast tilt,forward/backward	/ (°)	6/12
Mast height after mast fall	mm	1995
Fork lift maximum height	mm	4045
Free lift height	mm	150
Standard mast height	mm	3000
Overhead guard height	mm	2098
Overall length	mm	2353
Fork overhang	mm	468.5
From the rear	mm	384
Wheelbase	mm	1500
Minimum distance between the qround	mm	110
Tread (front/behind)	mm	970/950
Vehicle width	mm	1170
Fork size	mm	1070X125X45
Channel width	mm	4040
Turning radius	mm	2172
PERFORMANCE
Walking speed, loaded/withoutload	km/h	12/14
lifting speedjoaded/load	m/s	320/450
Dropping speed, loaded/without load	m/s	476/426
Maximum traction,loaded	N	18000
Max grade ability, loaded/without load	%	13/15
DRIVE
Drive motor power	kw	11
Lifting motor power	kw	12
Level voltage/capacitance	v/ah	48/630
OTHERS
Drive system	DC/AC
Electric control system	Curtis/lnmotion
Total weight	kg	4214

attachment of LTMG forklift

electric forklift attachments

LTMG forklift transportation

With a steadfast commitment to excellence in logistics, our team utilizes many measures to guarantee the utmost safety during transportation. Rigorous inspections, secure packaging, and expert handling techniques are employed to safeguard your valuable equipment.

FAQ

Q: What is the product range of our factory?

A: LTMG industrial is a large-scale machinery manufacturing enterprise primarily specializes in supplying all kinds of forklifts and related attachments. We can also customize non-standard products according to customer's requirements.

Q: Could we request our own color for the electric forklift?

A: Yes, of course, you just need to offer us the RAL code.

Q: What Certificates do we have?

A: All products meet with the ISO9001 Quality System and have acquired CE certificate. EPA approval will be available if needed.
