The Side Lift forklift is a remarkable piece of machinery that has become increasingly popular in recent years. With its unique design, this forklift is capable of lifting and transporting heavy loads safely and quickly. The Side Lift forklift is a versatile piece of equipment that can be used in a wide variety of settings, from warehouses to construction sites.
Side forklifts, also known as side loaders, have several advantages that make them a popular choice for material handling and storage operations.
Firstly, side forklifts are ideal for handling long and bulky loads, such as timber, pipes, and metal sheets. With their extended reach and ability to lift loads from either side of the machine, side forklifts make it easy to maneuver these types of loads in narrow aisles and tight spaces.
Secondly, side forklifts offer superior visibility and maneuverability. Because the operator sits at the side of the machine rather than behind it, they have a clear view of the load, the surrounding environment, and any potential hazards. This makes it easier for them to navigate through narrow aisles and tight corners without causing damage to the load or the surroundings.
Another advantage of side forklifts is their ability to handle loads on uneven surfaces. Side loaders are designed to distribute the weight of the load evenly across the vehicle, which means they can safely and easily handle loads on ramps, inclines, and other uneven surfaces.
Furthermore, side forklifts are highly efficient and can transport multiple loads at once. Because of their extended reach and ability to lift and stack multiple loads at once, they can save time and increase productivity in material handling and storage operations.
In summary, side forklifts offer several advantages over other types of forklifts. They are ideal for handling long and bulky loads, offer superior visibility and maneuverability, can handle loads on uneven surfaces, and are highly efficient and productive. All these advantages make side forklifts a valuable asset in any material handling and storage operation.
parameters
| Model | FDS60 | ||
| Power Type | Diesel | ||
| Rated Capacity | kg | 6000 | |
| Load Centre | mm | 600 | |
| Lift Height | mm | 3600 | |
| Fork Size | L×W×T | mm | 1220×150×60 |
| Mast Tilt Angle | F/R | Deg | 3°/3° |
| Ground Clearance(Bottom of mast) | mm | 245 | |
|
Overall Dimension |
L*W*T | mm | 5280*2100*3000 |
| Platform length | mm | 5280 | |
| Platform width | mm | 1200 | |
| Platform height | mm | 1080 | |
| Overhead Guard Height | mm | 2660 | |
| Turning Radius (outside) | mm | 4450 | |
|
Speed |
Travel (Empty load) | km/h | 18 |
| Lifting (Full load) | mm/s | 440 | |
| Max.Gradeability | % | 15 | |
|
Tyre |
Front | mm | 2×8.25-15-14PR |
| Rear | mm | 4×8.25-15-14PR | |
| Wheelbase | mm | 2900 | |
| Self weight | kg | 10140 | |
| Battery | Voltage/Capacity | V/Ah | (12/80) x 2 |
|
Engine |
Model | CY6102 | |
| Manufacture | Chaochai | ||
| Rated output/r.p.m. | kw | 82.4/2000 | |
| Rated torque/r.p.m. | N·m | 416/1400-1600 | |
| No.of Cylinder | 6 | ||
| Bore×Stroke | mm | 105×125 | |
| Displacement | cc | 6494 | |
| Fuel Tank Capacity | L | 178 | |
| Transmission | Type | Hydraulic | |
| Stage | FWD/RVS | 2/1 | |
| Operating Pressure for Attachment | Mpa | 19 | |
