product detail
1.8 Ton compact electric powered forklift is equipped with a world-renowned brand controller, meticulously calibrated for precise and efficient control of travel and lifting functions, delivering outstanding performance. The controller features advanced functions such as regenerative braking, slope braking, and self-diagnostic capabilities, enhancing operational safety and ease of use.
The fully enclosed design of the controller ensures protection against dust and water infiltration, while the easily accessible cover allows for convenient maintenance. With renowned components including the controller, battery, and gearbox, the 4 wheel electric forklift guarantees reliable performance and facilitates hassle-free servicing.
The high-efficiency AC system not only boasts comprehensive protection features but also comes equipped with temperature and speed sensors, ensuring higher reliability and an extended lifespan. The advanced H-type remote drive unit enhances the small electric forklift's structural integrity, offering a compact design with a lower center of gravity for improved stability and a more balanced layout, resulting in smoother travel.
Featuring a dynamic load sensing priority steering system, the electric power forklift delivers rapid steering response and enhanced stability during operation. The inclusion of temperature and speed sensors further contributes to the forklift's overall reliability and longevity.
LTMG 1.8 Ton compact electric powered forklift stands out with its precision control, advanced features, and reliable components. It is designed to meet the demands of diverse material handling applications, providing a seamless and efficient solution for your lifting and transporting needs.
Products parameter
| Model | FB18 | |
| Power type | Electric | |
| Rated capacity | mm | 1800 |
| Load center | mm | 500 |
| Tire type | solid tire | |
| Quantity of wheels | 2 X /2 | |
| Tires Size | 6.50-10-12PR/5.00-8-8PR | |
| Driving brake | Hydraulic-pedal | |
| Paking brake | Mechanical-manual | |
| Tilting Angles | α/β(°) | 6/12 |
| Height of mast | mm | 1995 |
| Max.lift height of mast | mm | 4025 |
| Free lift height | mm | 140 |
| Max.lift height of fork | mm | 3000 |
| Front-wheel Overhead | mm | 2100 |
| Length(without fork) | mm | 2035 |
| Front overhang | mm | 400 |
| Rear overhang | mm | 335 |
| Wheelbase | mm | 1360 |
| Min.ground clearance | mm | 110 |
| Tread(front/rear) | mm | 912/920 |
| Overall width | mm | 1150 |
| Fork size | mm | 920x100x40 |
| Minimum right Angle stacking channel width | mm | 3797 |
| Min mum urn radius | mm | 1997 |
| Max driving speed | km/h | 10~12 |
| Max Lifting speed | mm/s | 240~450 |
| Max lowering speed | mm/s | 480~420 |
| Maxmum tractive force | N | 8800 |
| Max.grade ability | % | 12~15 |
| Drive motor power | kw | 5.5 |
| Hoisting motor power | kw | 6 |
| Level voltage/Capacitance | V/Ah | 48/400 |
| Drive System | Full AC | Full AC |
| electric control system | Curtis | Curtis |
| Total weight | kg | 2980 |
Customer feedback
LTMG has expanded its market reach across several countries, offering top-notch customized services that align with diverse national policies and the unique work demands of our patrons, garnering heartening feedback from satisfied customers. LTMG prioritizes building lasting relationships with clients, enhancing our frequent journeys overseas to offer prompt assistance and ensure the intactness of our products.
oDM
LTMG is committed to providing customization services to customers throughout the world. It is convenient to change the color and logo to make your product a special one. The engine can be chosen among Euro3, Euro5, and EPA engines to comply with your emission control regulations. LTMG promises to do anything we can to satisfy your requirement.
lTMG FB18 customer feedback video
fAQ
Q: What is the approximate charging duration for the electric forklift's battery?
Q: What after-sales support does LTMG provide?
Q: Can we get the product as soon as possible?
