Small Electric Forklift Sale

The reasons for choosing three-pivot electric forklift may include the following aspects:

1. High space utilization: Due to its unique structural design (the front two wheels are driving wheels and the rear one is supporting wheel), three-pivot electric forklift has a small turning radius and can work flexibly in narrow aisles, which is especially suitable for space-restricted warehousing environments and improves the utilization of warehouse space.

2. Good operation stability: Although the three-pivot design seems to be unstable, in fact, through the reasonable counterweight and advanced suspension system, the three-pivot electric forklift truck maintains good stability during operation. Especially in the case of heavy load, the rear wheels are automatically pressed down to contact the ground to enhance the stability of the forklift.

3. Energy saving and environmental protection: Electric forklift trucks have no exhaust emission and low noise, which is in line with the increasingly strict environmental protection requirements. The use of electricity as a power source not only reduces the impact on the environment, but also in the use of the cost is lower than the internal combustion forklift.

4. Low maintenance cost: Compared with internal combustion forklifts, electric forklifts have lower maintenance cost. The structure of electric system is relatively simple, the failure rate is low, there is no need to regularly replace oil, air filter, etc., and the maintenance cost of electric motor is usually lower than that of internal combustion engine.

1. Specialized Packaging: -Package with special forklift trucks marine wooden crates or steel frames to provide external physical protection against collisions, scratches and seawater erosion. -Extra foam, bubble wrap or sponge wrapping of vulnerable parts of the forklift (e.g. control panels, hydraulic lines, mirrors, etc.) to provide cushioning protection.

2. Fixing and tying: -Use special fastening straps, chains or steel cables to fix the forklift firmly in the box or frame to prevent the equipment from shifting due to shaking during transportation. -If necessary, use wooden wedges or braces to support the forklift internally to prevent the equipment from sliding or tipping inside the box.

3. Anti-rust treatment: -Apply anti-rust treatment to the surface of the forklift, such as applying anti-rust oil or wrapping anti-rust film, to prevent the metal parts from rusting under the marine humid environment. -Waterproof sealing of electrical parts to prevent short circuit caused by moisture intrusion.

4. Equipment cleaning: - Thoroughly clean the forklift before transportation to remove grease, dust, etc. to avoid rusting or contamination of other goods during transportation.

3-WHEEL ELECTRIC FORKLIFT SPECIFICATION
General	1	Model			FB16S	FB18S	FB20S
	2	Power type			Electric	Electric	Electric
	3	Rated Capacity		kg	1600	1800	2000
	4	Load Centre		mm	500	500	500
Characteristic&Dimensions	5	Lift Height		mm	3000	3000	3000
	6	Fork Size	L×W×T	mm	920×120×35	920×120×35	1070×120×40
	7	Mast Tilt Angle	F/R(α°/β°)	Deg	6°/6°	6°/6°	6°/6°
	8	Front Overhang(Wheel center to fork face)		mm	390	390	395
	9	Tread	(F/R)	mm	924/208	924/208	924/208
	10	Ground Clearance(Bottom of mast)		mm	90	90	90
	11	Fork Spread	Min./Max.	mm	240/970	240/970	240/970
	12	Overall Dimension	Length to face of fork(Without fork)	mm	2100	2100	2105
	13		Overall Width	mm	1100	1100	1100
	14		Mast Lowered Height	mm	2010	2010	2010
	15		Mast Extended Height(With backrest)	mm	3940	3940	3940
	16		Overhead Guard Height	mm	2055	2055	2055
	17	Turning Radius(outside)		mm	1690	1690	1690
	18	Min. insecting aisle		mm	2300	2300	2300
Performance	19	Speed	Travel (Empty load)	km/h	14	14	14
	20		Lifting (Full load)	mm/s	340	320	300
	21	Max. Gradeability		%	15	15	15
Chassis	22	Tire	Front		18×7-8	18×7-8	18×7-8
	23		Rear		16×6-8	16×6-8	16×6-8
	24	Wheelbase		mm	1460	1460	1460
	25	Service Weight		kg	3420	3520	3760
Power & Transimission	26	Motor	Driven Motor	kw	2×4.5	2×4.5	2×4.5
	27		Lift  Motor	kw	8.6	8.6	8.6
	28	Battery	Voltage/Capacity	V/Ah	48/490	48/490	48/560
	29	Controller	Manufacturer		CURTIS	CURTIS	CURTIS
	30		Type		AC	AC	AC
	31	Operating Pressure for Attachment		Mpa	14.5	14.5	14.5

With technological innovation, our product configuration and parameters will continue to change without notice;

if there is any doubt, the specific confirmation of our international trade sales shall prevail;
