Products Description
A 3-wheeled electric forklift is ideally suited for indoor warehouse and distribution center environments where space optimization and maneuverability are crucial:
Using Environment:
•Narrow Aisles: With a compact design and a small turning radius, 3-wheeled electric forklifts can easily navigate through tight spaces and around obstacles in densely packed storage areas.
•Flat Surfaces: They perform best on smooth, level concrete floors and are less suitable for outdoor applications or rough terrain due to their inherent lower ground clearance and stability compared to four-wheeled models.•Indoor Climate: As electric forklifts produce no emissions, they are perfectly suited for enclosed spaces where air quality is a concern, such as food processing plants or pharmaceutical warehouses.
Advantages:
1. Maneuverability: The three-wheel configuration allows for a tighter turning circle, enabling operators to turn quickly and accurately, enhancing productivity in confined spaces.
2. Energy Efficiency: Electric forklifts consume less energy and have lower operating costs than their internal combustion counterparts. They are also quieter, creating a more comfortable work environment.
3. Eco-Friendly: No tailpipe emissions mean cleaner air in the workplace and a reduced carbon footprint, which aligns with green initiatives.
4. Low Maintenance: Electric motors have fewer moving parts than internal combustion engines, requiring less frequent and less complex maintenance. Battery maintenance is manageable with proper charging and scheduled inspection.
5. Cost Savings: While the initial investment for electric forklifts can be higher, their lower operating and maintenance costs over time can result in significant savings. Additionally, there are often government incentives for using electric vehicles.
In summary, a 3-wheeled electric forklift is a smart choice for businesses looking to maximize space utilization, reduce environmental impact, and improve operational efficiency in controlled indoor settings.
Products Description
| Model | FB20S | ||
| Power type | Electric | ||
| Rated Capacity | kg | 2000 | |
| Load Centre | mm | 500 | |
| Lift Height | mm | 3000 | |
| Fork Size | L×W×T | mm | 1070×120×40 |
| Mast Tilt Angle | F/R(α°/β°) | Deg | 6°/6° |
| Front Overhang(Wheel center to fork face) | mm | 395 | |
| Tread | (F/R) | mm | 924/208 |
| Ground Clearance(Bottom of mast) | mm | 90 | |
| Fork Spread | Min./Max. | mm | 240/970 |
| Overall Dimension | Length to face of fork(Without fork) | mm | 2105 |
| Overall Width | mm | 1100 | |
| Mast Lowered Height | mm | 2010 | |
| Mast Extended Height(With backrest) | mm | 3940 | |
| Overhead Guard Height | mm | 2055 | |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail
FAQ
Q: How much weight can a standard 3-wheel electric forklift lift?
Q: Is a 3-wheel electric forklift suitable for uneven surfaces?
