Self-Propelled Conveyor Belt Loader

A self-propelled conveyor belt loader is a specialized vehicle used in airports and other logistics operations for loading and unloading cargo onto aircraft. It typically consists of a conveyor belt system mounted on a vehicle chassis that can move independently.
Send Inquiry
Chat Now

Product Introduction

The features and advantages of Self-Propelled Conveyor Belt Loaders:

1. Mobility: The self-propelled nature of these baggage belt loader allows them to move around the airport independently without requiring external towing. This makes them highly maneuverable and efficient in handling cargo at various locations on the tarmac.

2. Versatility: They can be used for loading and unloading cargo from a variety of aircraft, including narrow-body and wide-body planes. This versatility makes them suitable for different types of cargo operations.

3. Adjustable Conveyor Height: The conveyor belt height can often be adjusted to match the cargo hold of different aircraft. This feature ensures efficient and safe transfer of cargo, accommodating the varying heights of cargo holds on different planes.

4. Time Efficiency: Self-propelled conveyor belt loaders can significantly reduce turnaround times for aircraft. Their ability to move quickly and position themselves directly alongside the aircraft allows for faster loading and unloading operations.

5. Reduced Manual Labor: With the conveyor belt system, manual handling of cargo is minimized. This not only increases efficiency but also reduces the risk of injuries to ground handling personnel.

6. Payload Capacity: The luggage belt loaders are designed to handle a substantial payload, allowing them to efficiently move large quantities of cargo in a single operation.

7. Safety Features: Self-propelled conveyor belt loaders often come equipped with safety features such as sensors and alarms to prevent accidents or collisions during operation.

8. Fuel Efficiency: Modern models may incorporate fuel-efficient engines and advanced technologies to optimize fuel consumption, contributing to environmental sustainability and cost-effectiveness.

9. Remote Control Options: Some models may offer remote control capabilities, allowing operators to control the loader from a distance for increased precision and safety.



aircraft conveyor belt loader



gse belt loader


technical specifications



Characteristic
1 Model   BLB80
2 Power Mode   Battery
Weight
3 Service Weight kg 4800
4 Front Axel Load kg 2700
5 Rear Axle Load kg 2100
Tire and Wheelbase
6 Tire     Inflatable Tire
7 X Drive Wheel     4X2
8 Front Tire Specification   195R15C
9 Rear Tire Specification   195R15C
10 Front Wheel Thread mm 1700
11 Read Wheel Thread mm 1690
12 Wheelbase mm 2990
Dimensions
13 Transfer Extend Range (Front) mm 990-4560
14 Transfer Extend Range (Rear) mm 540-1650
15 The Highest Extend Angles ° 25
16 THe Max Transfer Angles ° 30
17 THe Conveyor Height (F/R:Driving) mm 1120/860
18 Belt Width mm 600/700
19 The Max. Transfer Width
(Baggage Board Turned Over)

mm

835

20 Overall Length mm 8090
21 Overall Width mm 2000
22 Overall Height
(Without/With Cabinet)
mm 1640/1995
24 Hanging Distance Front mm 1335
25 Hanging Distance Rear mm 660
26 Approach Angles ° 16
27 Departure Angles ° 17
28 Turning Radius   mm 6000
29 Ground Clearance mm 135
30 The Minimum Outer Diameter for the Driving Channel mm 12000
Performance
31 Travel Speed (No Load) km/h 25
32 Min Steady Speed mm/s 2.5
33 Max. Tranfer Unit Kg 400
34 Max. Load Ability on Average Kg/m 135
35 Belt Transfer Speed (Forward) m/s 0.2-0.5
36 Belt Transfer Speed (Backward) m/s 0.2-0.5
37 Extend Speed(Front/Rear) s 30/1O
38 Lowered Speed (Front/Rear) s 30/1O
39 Gradeability % 8.3
40 Endurance Miles Km 55+





the transportation of belt loader



belt loader aircraft





FAQ



Q: Can we provide OEM service?

A: LTMG can provide customized products according to customers' requirements, both OEM and ODM are acceptable.

Q: What is LTMG payment term of the wheel loader machine?

A: T/T, L/C
