1. Powerful Yanmar TNE98 Series Diesel Engine: Unleash unparalleled power and efficiency with the Japanese-engineered Yanmar TNE98 series direct injection diesel engine. Renowned for its robust performance, this engine delivers exceptional power output to tackle even the most demanding towing tasks with ease.

2. Independent Suspension Steering Axle: Experience enhanced maneuverability and minimized space occupation with the independent suspension steering axle. This innovative design allows for precise handling and navigation in tight spaces, ensuring optimal control and agility.

3. High-Strength Integral Central Single-Stage Reduction Drive Axle: Built for maximum durability and performance, the high-strength integral central single-stage reduction drive axle boasts superior strength, rigidity, and high transmission efficiency. With its impressive load-bearing capacity, it can effortlessly handle heavy loads, making it ideal for intensive towing operations.

4. Hydraulic Transmission with Original Imported Automatic Transmission: Benefit from smooth and seamless operation with the original imported automatic transmission featuring hydraulic transmission technology. This advanced system ensures effortless gear shifts and optimal performance, enhancing productivity and efficiency on the job.

Elevate your baggage handling operations to new heights of efficiency and reliability with our Baggage Towing Tractor. Designed to exceed expectations, it's the ultimate solution for your towing needs, offering unparalleled power, precision, and performance.

airport baggage tug

tractor luggage

tug baggage tractor

technical parameters

Model					TD25
Performance	Max. drawbar pull			KN	25
	Max. towed weight	With one trailer		Kg	32000
		With a train of trailers		Kg	49000
	Max. travel speed	Forward		Km/h	35
		Backward		Km/h	14
	Min. turning radius			mm	5900
	Max. gradeability with no load			%	38
Weight	Truck weight(no load)			Kg	3450
	Weight distribution	Front		Kg	1120
		Rear		Kg	2480
Dimensions	Outline dimension	Overall length		mm	3025(with towing bar)
		Overall width		mm	1440
		Overall height		mm	1450
	Wheelbase			mm	1600
	Wheelbase	Front		mm	1230
		Rear		mm	1170
	Front overhang			mm	630
	Rear overhang			mm	770
	Towing bar height			mm	304.8/405
	Min. ground clearance			mm	150
Engine	Model				Yanmar98
	Displacement			cm³	3319
	Rated output			KW/rpm	43.7/2300
	Max. torque			N.m/rpm	196.3/1700
	Max. speed			rpm	2625
Transmission	Model				Okamura
	Gearshift method				Automatic 2 speed
	Transmission gear ratio		Forward gear I		2.550
			Forward gear 2		1.241
			Backward gear 1		2.550
Tire	Front				6.50-10
	Rear				7.00-15
Brake	Service brake				Hydraulic
	Parking brake				Mechanical

FAQ

Q: What is a baggage towing tractor, and what is its primary function?

A: A baggage towing tractor is a specialized vehicle designed for towing baggage carts and other ground support equipment at airports. Its primary function is to transport baggage and cargo efficiently around the airport tarmac.

Q: How does the hydraulic transmission with an original imported automatic transmission benefit users?

A: The hydraulic transmission system offers smooth and seamless gear shifts, enhancing operator comfort and productivity. The original imported automatic transmission ensures reliable performance and durability, minimizing downtime and maintenance costs.

Q: Can the baggage towing tractor be customized to meet specific requirements?

A: Yes, we offer customization options to tailor the baggage towing tractor to your specific needs, including paint colors, additional features, and specialized attachments for different types of baggage handling equipment.
