Products Description
Unveiling our cutting-edge 2-ton Three-Wheel Operated Electric Forklift, a marvel of engineering designed to excel in the most demanding warehousing and industrial environments. This innovative vehicle not only embodies sustainability but also pushes the boundaries of efficiency and operator comfort, making it the ideal choice for businesses committed to green logistics and optimized workflows.
At the heart of its eco-friendly design lies the advanced regenerative braking system. Unlike conventional forklifts, our operated electric forklift harnesses energy during deceleration, downhill motion, or directional changes, converting the drive motor into a generator. This harvested kinetic energy is then fed back into the battery via a sophisticated controller, significantly enhancing energy efficiency and extending operational hours between charges. It's a game-changing feature that underscores our commitment to reducing carbon footprint while boosting productivity.
Built for versatility, each unit in our 2-ton range boasts a strategically placed lifting point, meticulously engineered to facilitate seamless handling by port cranes. This unique inclusion enables the forklift to be effortlessly lifted and positioned aboard vessels, expanding its operational scope to encompass marine cargo handling – a capability that sets it apart in versatility and adaptability.
Understanding the importance of accessibility for maintenance, we have ingeniously centralized the electrical components beneath the protective hood, nestled in the midsection of the vehicle. This strategic placement not only safeguards vital electronics from potential damage but also streamlines repair and maintenance tasks, ensuring minimal downtime and reduced service costs.
Taking operator comfort and load handling precision to new heights, our model integrates both the Soft Landing System and the Soft Lifting System. These innovative mechanisms, applied to the front lifting cylinders of triplex masts and full-free duplex masts respectively, guarantee a drastic reduction in mast noise and vibrations during lifting and lowering operations. The result is a smoother, quieter workplace that promotes safety, prolongs the lifespan of the forklift, and significantly enhances the overall operating experience


In essence, our 2-ton Three-Wheel Operated Electric Forklift is a testament to the future of materials handling – a harmonious blend of ecological sensibility, operational excellence, and user-centric design. Whether navigating narrow aisles, executing precision lifts, or tackling challenging marine environments, this electric powerhouse promises to redefine efficiency, all while upholding the highest standards of environmental responsibility. Experience firsthand the evolution of powered industrial trucks and elevate your logistics capabilities with our groundbreaking forklift solution.
About LTMG
attachment
certification
Model |
FB20S |
||
Power type |
Electric |
||
Rated Capacity |
kg |
2000 |
|
Load Centre |
mm |
500 |
|
Lift Height |
mm |
3000 |
|
Fork Size |
L×W×T |
mm |
1070×120×40 |
Mast Tilt Angle |
F/R(α°/β°) |
Deg |
6°/6° |
Front Overhang(Wheel center to fork face) |
mm |
395 |
|
Tread |
(F/R) |
mm |
924/208 |
Ground Clearance(Bottom of mast) |
mm |
90 |
|
Fork Spread |
Min./Max. |
mm |
240/970 |
Overall Dimension |
Length to face of fork(Without fork) |
mm |
2105 |
Overall Width |
mm |
1100 |
|
Mast Lowered Height |
mm |
2010 |
|
Mast Extended Height(With backrest) |
mm |
3940 |
|
Overhead Guard Height |
mm |
2055 |
|
Turning Radius(outside) |
mm |
1690 |
|
Min. insecting aisle |
mm |
2300 |
|
Speed |
Travel (Empty load) |
km/h |
14 |
Lifting (Full load) |
mm/s |
300 |
|
Max. Gradeability |
% |
15 |
|
Tire |
Front |
18×7-8 |
|
Rear |
16×6-8 |
||
Wheelbase |
mm |
1460 |
|
Service Weight |
kg |
3760 |
|
Motor |
Driven Motor |
kw |
2×4.5 |
Lift Motor |
kw |
8.6 |
|
Battery |
Voltage/Capacity |
V/Ah |
48/560 |
Controller |
Manufacturer |
CURTIS |
|
Type |
AC |
||
Operating Pressure for Attachment |
Mpa |
14.5 |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail;
