The electric power pallet jack is a material handling product that offers superior performance, ease of use, and durability. This versatile machine is designed to meet the demands of the most challenging warehouse environments, providing unbeatable value for its users.
Electric pallet trucks are widely used in warehouses and manufacturing facilities to move heavy loads swiftly and efficiently. They are powered by a rechargeable battery and require minimal effort to operate. With the addition of a weighing scale, electric pallet trucks have become even more useful in various industrial applications.
The weighing scale on the electric pallet truck is a game-changer as it enables users to weigh goods while moving them around. This feature saves time and effort as there is no need to transfer goods to a separate weighing scale. The entire process of loading, moving, and unloading can be completed in one go, which increases efficiency and saves time.
Another advantage of electric pallet trucks with weighing scales is that they improve accuracy. The scale displays the exact weight of the load, eliminating guesswork and errors caused by manual weighing. This is beneficial in industries where weight accuracy is crucial, such as in pharmaceuticals or chemical manufacturing.
Electric pallet trucks with weighing scales are also known for their user-friendliness. They come equipped with a simple interface that makes them easy to operate. Additionally, electric pallet trucks have a faster turnaround time, enabling workers to complete more tasks throughout the day.
In conclusion, electric pallet trucks with weighing scales are an excellent investment for companies that want to increase efficiency and accuracy while reducing their carbon footprint. They are easy to use, versatile, and have a host of benefits that make them a valuable addition to any warehouse or manufacturing facility.
Technical parameters
Model | SHF20 | |
Feature | ||
Loading capacity | kg | 2000 |
Load center | mm | 600 |
Wheel base | mm | 1301 |
Operating type | mm | Walkie |
Wheels | ||
Wheels type | PU | |
Wheel quantity driving | mm | 1/0/4 |
Driving wheel size | mm | 252*67 |
Bearing wheel size | mm | 84*70 |
Balane wheel size | mm | |
Dimension | ||
Min.fork lifting height | mm | 85 |
Max.fork lifting height | mm | 205 |
Max.lifting height | 120 | |
Overall fork width | mm | 550/685 |
Inside width between forks | mm | 230/365 |
Fork length | mm | 1150/1200 |
Fork width | mm | 160 |
Fork thickness | mm | 75 |
Overall length | mm | 1707 |
Overall width | mm | 697 |
Overall height(with handle) | mm | 1181 |
Overall height(without handle) | mm | 714 |
Min.turning radius | mm | 1547 |
Min.Aisle with for pullets 800*1200 | mm | 1920 |
Min.Aisle with for pullets 1000*1200 | mm | 1953 |
Performance | ||
Travel speed,laden/unlades | km/h | 3/3.5 |
Lift speed,laden/unlades | mm/s | 35/40 |
Lowering speed,laden/unlades | mm/s | 45/40 |
Gradeability,laden/unladed | % | 5/7 |
Electrical configuration | ||
Drive motor | kW | DC 0.63 |
Lift motor | kW | DC 0.8 |
Battery voltage/capacity | V/aH | 24/85 |
Brake | Electromagnetic | |
Controller | CURTIS | |
Weight | ||
Battery weight | kg | 52 |
Service weight with battery | kg | 245 |
Factory
Shipping
About LTMG
LTMG Machinery ensures the safe transportation of electronic pallet trucks to customers. We understand the importance of delivering cargo securely and efficiently, prioritizing the satisfaction and trust of our valued clients. Our commitment to safety, efficiency, and customer satisfaction sets us as a trusted partner.
FAQ
Q: What types of products does LTMG specialize in?
Q: What is LTMG's policy for responding to customer questions and concerns?
Q: Advantages of electric pallet trucks with weighing scales
Hot Tags: electric pallet truck with weighing scale, China electric pallet truck with weighing scale manufacturers, Small Side Loader Forklift, warehouse picker machine, Diesel Forklift, Telescopic Forks Forklift, mobile elevated platform, High Capacity Lift Trucks
