One notable characteristic of three-wheel electric forklifts is their relatively high ground clearance. This feature enables the machinery to traverse uneven surfaces, inclines, or surfaces littered with obstacles like debris or small ramps more efficiently than some other types of forklifts. The ample space between the lowest point of the truck and the ground reduces the risk of grounding, protecting vital components from damage and ensuring uninterrupted operation even in less-than-ideal conditions. electric forklift trucks for sale This adaptability makes them suitable for both indoor and outdoor use where the terrain might not always be perfectly smooth.
A defining advantage of three-wheel electric forklifts lies in their exceptionally tight turning circles. The unique tri-wheel configuration, with a single drive wheel at the rear and a steered twin-wheel assembly at the front, allows for a turning radius that can be up to 30-50% smaller than equivalent four-wheel models. electric forklift trucks for sale This capability is transformative in confined spaces such as narrow warehouse aisles, crowded storage facilities, or busy production lines. The ability to pivot on its central axis means these vehicles can execute swift, precise turns, greatly enhancing maneuverability and productivity within limited work areas.
Products parameter
| Model | FB18S | |
| Power type | electric | |
| Rated capacity | kg | 1800 |
| Load center | mm | 500 |
| Tire type | pneumatic tyre | |
| Mast Tilt Angle | α/β(°) | 6°/6° |
| Fork Size | mm | 920×120×35 |
| Front Overhang(Wheel center to fork face) | mm | 390 |
| Tread | mm | 924/208 |
| Ground Clearance(Bottom of mast) | mm | 90 |
| Fork Spread | mm | 240/970 |
| Length to face of fork(Without fork) | mm | 2100 |
| Overall Width | mm | 1100 |
| Mast Lowered Height | mm | 2010 |
| Service Weight | kg | 3420 |
| Driven Motor | kw | 2×4.5 |
| Lift Motor | kw | 8.6 |
| Voltage/Capacity | V/Ah | 48/490 |
| Manufacturer | CURTIS | |
| Type | AC |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail;
Company Introduction
FAQ
Q:How long can a three-wheel electric forklift operate on a single charge, and what factors influence its runtime?
Q: Is it possible to extend the working hours of a three-wheel electric forklift beyond its standard runtime? If so, how?
