Name: Diesel Forklift Uae
Brand: LTMG
SKU: 234553862

Product Introduction

LTMG certification

Certificate of Registration (COR): A COR certificate is usually a certificate of registration that is required for the importation of products in certain countries and regions. For example, in Iraq, a COR is a certificate of product registration issued by the Central Organization for Standardization and Quality Control (COSQC), and importers must ensure that the product has been successfully registered and has passed the relevant standards and regulations before importing certain goods into Iraq.

COC Certificate (Certificate of Conformity): A COC certificate is a certificate proving that a product complies with the specific standards and regulations of the importing country. In international trade, many countries require imported goods to provide COC certificate to prove that the product meets the local health, safety, environmental protection, quality and other related standards. For example, Saudi Arabia's SASO-CoC certificate is a certificate of conformity issued by the Saudi Arabian Standards Organization (SASO), without which products cannot be sold in the Saudi Arabian market.

lTMG forklift characteristics

1. Spacious operating space.

2. Steering column that can be adjusted at a large angle according to the needs of the driver

3. The design of the joystick position is more ergonomic and can reduce the driver's fatigue.

4. The arrangement of the instruments is reasonable, which enables the driver to observe the running state of the car at a glance.

5. Larger pedal contact surface, extra-long safety rack armrest, and unique lower armrest design make it very easy for the operator to get on and off the vehicle.

6. The unique side armrest design makes the driver feel more secure when reversing.

7. Large and comfortable seat with cushioning function,

8. Large arc reversing mirror, bright field of vision.

9. Competitive vision gantry to improve operational efficiency.

10. The position of the emergency power-off switch is close to the driver, so that the driver can cut off the power in a short time.

protection measures in transportation

Moisture and waterproofing: - For marine transportation, moisture and waterproofing measures must be taken, such as wrapping waterproof film or using waterproof cover, to ensure that the electrical components and precision parts are not affected by seawater erosion and humidity.For battery forklift trucks, the battery should be properly placed to ensure that it will not be damaged by shaking and bumping, and the battery liquid should not be spilled to avoid environmental pollution and fire hazards.

1.Dismantling of Sensitive Components: For fragile components that are easily damaged during transportation, temporary dismantling and separate packaging can be an option, e.g., removable forks, certain attachments, etc.

2. Thorough Record Keeping and Labeling: Record the condition of the forklift and the results of all pre-loading and shipping inspections, including a photographic record, labeled with information such as factory date, model number, and serial number. And make eye-catching markings on the forklift to remind the transporter of the precautions to be taken and the correct way of loading.

3. Insurance and Documentation Preparation: Apply for the appropriate freight insurance to ensure that the forklift can be financially compensated in case of loss during transportation. At the same time, prepare all necessary export documents and shipping documents.

4. Professional guidance and supervision: Professional and technical personnel can be invited to guide the loading process to ensure that all protective measures can be correctly implemented, and in the loading process of the whole process of supervision, to ensure that the forklift trucks in the loading, transportation and unloading of the various aspects of safety. Through the above measures, we can minimize the risk of damage to the forklift during the shipping process and ensure that the equipment can be delivered to the destination in good condition.

About forklift customizability

LTMG customized service

Products parameters

Technical Parameter
Item		Unit	FD350
Features	Rated Load	Q(Kg)	35000
	Load Center	c(mm)	1250
	Wheelbase	y(mm)	4800
Weight	Weight	kg	42000
Chassis	Tire Specs:Front		16.00-25-32PR
	Tire Specs:Rear		16.00-25-32PR
	Tires Qty,front/rear(X-dreve wheels)		4/2
	Wheel tread:Front	b3(mm)	2430
	Wheel tread:Rear	b4(mm)	2240
Dimensions	Mast/carriage tilt angle(front/rear)	Degree(°)	6/12
	Mast height(fork lowering)	h1(mm)	4010
	Mast lifting height	h2(mm)	3000
	Max.height	h3(mm)	5980
	height to head guard(height to cab)	h4(mm)	3770
	Overall height(with forks)	L3(mm)	9640
	Fork front verticaal sueface to the rear end of the vehicle	L2(mm)	7240
	Overall width	b1(mm)	3360
	Fork dimension	(mm)	2400300120
	Fork carriage width	b2(mm)	3000
	Mast min ground(with load)	m1(mm)	400
	Wheelbase center min ground(with load)	m2(mm)	460
	Min.turning Radius	Wa(mm)	6600
	Travel speed(with load/without load)	km/h	25/28
Performance	Max.lifting speed(with load/without load)	mm/s	260/280
	tractionn	KN	220
	gradeability(with load/without load)	%	20/20
	Driving brake		Hydraulic clamp disvc
Engine	Engine brand/model		Weichai Engine
			WP10G240E21
		Cylinder No	6
Others	Transmission gears(Front/rear)		2/1

With technological innovation, our product configuration and parameters will continue to change without notice;

if there is any doubt, the specific confirmation of our international trade sales shall prevail;
