The design of telescopic fork trucks not only enables the forklift to move back and forth, but also allows the telescopic boom length, which makes the forklift trucks to easily handle cargo loading and unloading tasks that can't be fulfilled by other forklift trucks. The long arms make it easy to manoeuvre loads and move them from one extreme position to the other, reducing the number of times an operator needs to get out of the truck or use other equipment, thus increasing efficiency.

tele forklift

Telescopic fork truck can also help in handling loads of different sizes and weights. This type of forklift can operate a wider range of goods, including large heavy loads, box loads and long objects, and can be adapted to a wide variety of usage environments and sites.

Specification

Model	FT50
Rated load	5000Kg
Maximum lifting height	7m
Maximum reach	6.80m
Overall length (to forklift)	6.08m
Overall width	2.26m
Overall height	2.54m
Wheelbase	3.3m
Ground Clearance	0.4m
Turning Diameter	4m
Unladen weight	11000Kg
Cab Width	0.9m
Standard Tires	16/70-24
Standard Forks	1200×125×45
Lift	7.20S
Lowering	5.50S
Extend	6.50S
Retract	5.40S
Upper tipping (filling)	2.90S
Downward tipping (unloading)	2.80S
Engine
Brand name	Yuchai
Emission standard	National III
Model	YC4DK90-T304
Cylinder-displacement	4-3.621L
Power	66Kw
Maximum torque	350N.m
Transmission mode	Torque converter
Number of gears	Front 4 Rear 3
Maximum speed	34km/h
Brake form	Dual-axle oil-absorbed multi-disc brakes
Hydraulic oil	450L
Diesel oil	260L

Application

application of telescopic fork truck

A telescopic boom forklift truck is a forklift truck that can telescope its arms to extend the load to lift heights.

High lifting height: Telescopic boom forklifts can lift very high loads, which is very useful for large warehouses or factories. They can easily move goods to high places without being affected by height restrictions. The long arms of the telescopic boom forklift trucks can balance the centre of gravity of the heavy load to some extent, thus reducing the risk of swaying and tilting of the load.

To sum up, telescopic boom forklift trucks have the advantages of easy storage, high lifting height, high efficiency, safety and reliability, and versatility. For large warehouses or factories, telescopic boom forklifts are one of the indispensable mobile equipment.

Shipping plan

shipping plan of telescopic fork truck

FAQ

1. How can i get to your factory?
You can contact us and we can arrange and pick you up in the airport.

2. As the shipping period will take long time, how can you make sure the machine won't be broken?
Our machine is film wrapped, to make sure the machine can be delivered to our customer smoothly, we will use the steel wire to fix the machine with the container.

3. About the after-sale service, how can you solve the problems occurred of your overseas customer in time?
The warranty of our machine is normally 12 months, during this period, we will arrange the international express immediately, to make sure the replace parts to be delivered as soon as possible.

4. Do you have the products in stock?
No. All bikes are to be produced according to your order including samples.
