Equipped with a hydraulic balance valve, our small telescopic handler forklift diesel engine ensures controlled descent and extension speed, preventing uncontrolled descent of heavy loads. The hydraulic lock control for the front and rear legs guarantees secure leg locking, preventing instances of "soft legs" during lifting operations or unintentional leg lowering during transportation.
Featuring an adjustable steering system and aviation-style seating, the tele handler forklift provides a comfortable and ergonomic operating environment. The use of pilot valve-controlled distribution valves for the hydraulic system ensures light and responsive operation, enhancing maneuverability. The ergonomic design extends to the overall comfort, making the operator experience more pleasant.
The standard configuration includes fork attachments, a high-altitude working platform, and a frame manipulator. Widely applied in tunnels, ports, construction sites, industrial facilities, agriculture, livestock, municipal firefighting, and more, it excels in loading, stacking, short-distance transport, and high-altitude operations.
Boasting an elegant and streamlined appearance, the telescopic reach forklift stands out with its contemporary design. The spacious and luxurious cabin offers a wide field of view, complete with a skylight, ensuring low noise levels and excellent sealing for a conducive operator environment. The design facilitates a comprehensive observation of the surroundings, prioritizing safety and operational awareness.
LTMG's small telescopic handler forklift diesel engine combines cutting-edge technology with a focus on safety and operator well-being. From controlled hydraulic systems to ergonomic design, this forklift is engineered to meet the diverse needs of modern material handling operations.
Products Parameter
| Model | unit | Deviation allowed | FT35 |
| Rated load | kg | - | 3500 |
| Load center | mm | - | 500 |
| Load capacity | kg | - | 1550 |
| Basic boom max. Lifting height | mm | ±1.5% | 4850 |
| Max. Lifting height | mm | ±1.5% | 7000 |
| Max. Horizontal reach | mm | ±1.5% | 3350 |
| Min. Horizontal reach | mm | ±1.5% | 930 |
| Min. Ground clearance | mm | ±1.5% | 400 |
| Min. Turning radius ( outer tyre center) | mm | ≤105% | 6200 |
| Boom frame upward angle | ° | ±1.0 | 60 |
| Boom frame downward angle | ° | ±1.0 | 11 |
| Operating weight | kg | ±5% | 9000 |
| Length (with fork) | mm | ±2% | 5730 |
| Width | mm | ±2% | 2390 |
| Height | mm | ±2% | 2485 |
| Wheel tread | mm | ±1% | 1870 |
| Wheel base | mm | ±1% | 2700 |
| Rated power / Rated turning speed | KW/rpm | - | 60/2000 |
| Max. Travelling speed (unloaded) | km/h | ±10% | 30 |
| Gradeability | % | - | ≥30% |
| Front (2 pcs) | - | - | 16/70-24 |
| Rear (2 pcs) | - | - | 10.00-20-16 |
video
Operating conditions
This efficient machine is widely utilized in factories, stations, docks, freight yards, post and telecommunications facilities, forests, building materials sectors, warehouses, and other similar locations.
FAQ
Q: Could you offer an overview of LTMG as a company?
A:LTMG has earned the prestigious title of the best-selling forklift brand on Alibaba for three consecutive years. Our excavator sales consistently secure a spot in the top five, and our loaders consistently rank among the top three. This outstanding achievement reflects our unwavering dedication to providing top-quality products at competitive prices. The numerous accolades and recognition bestowed upon us by satisfied customers further underscore our commitment to excellence.
Q: Are your products readily available?
Q: Can l visit your factory?
A:By all means, we warmly welcome your arrival, Before you take off from your country, please let us know. We will show you the way and arrange time to pick you up if possible.
