Products Description
Versatile Articulation: With multiple articulating joints, this boom lift offers exceptional flexibility and reach, allowing operators to navigate around obstacles and reach difficult-to-access areas with ease.
Quiet Operation: Its electric motor ensures quiet operation, making it suitable for indoor use or in noise-sensitive environments such as residential areas, hospitals, or schools.
Compact Design: Despite its impressive reach, the boom lift features a compact design, making it easy to maneuver in confined spaces and navigate through narrow aisles or doorways.
Smooth Controls: Equipped with intuitive controls, operators can easily maneuver the boom lift with precision, enhancing productivity and safety on the job site.
Safety Features: Built-in safety features such as tilt sensors, overload protection, and emergency stop buttons ensure the safety of both operators and bystanders during operation.
Platform Capacity: The platform offers ample space and a high weight capacity, allowing operators to comfortably work at height with tools and materials.
Reach and Height: With impressive reach and height capabilities, this boom lift can access elevated work areas, making it ideal for tasks such as construction, maintenance, and installation projects.
Outriggers for Stability: Equipped with outriggers, the boom lift provides additional stability when working at height, ensuring a secure and stable platform for operators.
Easy Transport and Setup: Designed for easy transport and quick setup, this boom lift can be deployed rapidly, minimizing downtime and maximizing productivity on the job site.
Maintenance Accessibility: The design incorporates easy access points for routine maintenance and servicing, reducing downtime and ensuring optimal performance over the long term.
specification
|
Model |
LTQE1012 |
LTQE1214 |
LTQE1416 |
LTQE1618 |
LTQE1820 |
LTQE2022 |
|
|
Measurements |
|||||||
|
Working height maximum |
m |
12 |
14 |
16 |
18 |
20 |
22 |
|
Platform height maximum |
m |
10 |
12 |
14 |
16 |
18 |
20 |
|
Horizontal reach maximum |
m |
5.8 |
8 |
8.1 |
10 |
10.8 |
12.3 |
|
Up Stover clearance maximum |
m |
4.78 |
5 |
7.6 |
7.6 |
9.2 |
9.2 |
|
(LxW ) Platform dimensions(LxW) |
m |
1.1x0.65 |
1.53x0.76 |
||||
|
Length(stowed) |
m |
4.35 |
5.3 |
6.24 |
7.9 |
8.1 |
9.2 |
|
Width(stowed) |
m |
1.5 |
2 |
1.75 |
2 |
2.38 |
2.38 |
|
Height(stowed) |
m |
1.99 |
2.05 |
2 | 2 |
2.38 |
2.34 |
|
Wheelbase |
m |
1.65 |
2 | 2 | 2.2 |
2.6 |
2.6 |
|
Ground clearance(center) |
m |
0.15 |
0.2 |
0.2 |
0.2 |
0.3 |
0.3 |
|
Productivity |
|||||||
|
Lift capacity maximum |
kg |
200 |
230 |
230 |
|||
|
Platform occupancy maximum |
2 |
||||||
| Platform rotation | ±80° | ||||||
| Vertical jib rotation | 140° | ||||||
| Turntable rotation | 355° | ||||||
|
Turntable tailswing |
m |
0.25 |
0.13 |
0 |
0 |
0.33 |
0.33 |
|
Drive speed (stowed) |
km/h |
3 |
3 |
5 |
5 |
5 |
5 |
|
Drive speed (raised) |
km/h |
0.8 |
0.8 |
0.8 |
0.8 |
0.8 |
0.8 |
|
Gradeability |
25% |
30% |
25% |
||||
| Working slope maximum | 3°/3° | ||||||
|
Turning radius(inside) |
m |
2.16 |
2.2 |
2.68 |
2.98 |
2.66 |
2.66 |
|
Turning radius(outside) |
m |
3.44 |
4.73 |
4.24 |
4.62 |
5.66 |
5.66 |
|
Drive & steer mode |
4x2x2 |
||||||
|
Tire type |
0.59x0.19 |
28x9-15 |
33x12-20 |
||||
|
Power |
|||||||
|
Battery |
48V/320Ah |
48V/390Ah |
|||||
|
Pump electric motor power |
7.5 |
5 |
|||||
|
Drive electric motor power |
kW |
/ |
6.5x2 |
||||
|
Control voltage |
24V DC |
||||||
|
Charger |
48V/50A |
48V/62A |
|||||
|
Weight |
kg |
4800 |
5500 |
6270 |
6720 |
8080 |
8200 |
Detail of the electric articulating booms
Shipping package picture
FAQ
Q: What are the primary applications for electric articulating boom lifts?
Q: How does an electric articulating boom lift differ from other types of boom lifts?
Q:What safety features are included with electric articulating boom lifts?
