Products parameter
Model | FB25 | |
Power type | electric | |
Rated capacity | kg | 2500 |
Load center | mm | 500 |
Tire type | pneumatic tyre | |
Mast tilt,forward/backward | α/β(°) | 6/10 |
Mast height after mast fall | mm | 2185 |
Fork lift maximum height | kg | 4170 |
Free lift height | kg | 150 |
Standard mast height | kg | 3000 |
Overhead guard height | mm | 2092 |
Overall length | mm | 2507 |
Fork overhang | mm | 475 |
Wheelbase | mm | 1600 |
From the rear | mm | 472 |
Minimum distance between the qround | mm | 110 |
Tread (front/behind) | mm | 1000/970 |
Vehicle width | mm | 1220 |
Fork size | mm | 1070X125X45 |
Channel width | mm | 4150 |
Turning radius | mm | 2360 |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail;
