The Diesel Driven Forklift is a popular choice for heavy lifting applications across industries. It is known for its high performance, exceptional fuel efficiency, and low maintenance costs. However, the choice of engine can make a significant difference in how well the forklift performs.
The Cummins engine offers superior performance and power, ensuring that the forklift can handle even the most challenging loads with ease. The engine's exceptional torque and horsepower provide quick acceleration, smooth operation, and impressive lifting power. Additionally, the Cummins engine has impressive fuel efficiency, which translates to lower fuel costs and a significant reduction in emissions.
Reliability is key when it comes to heavy-lifting equipment, and the Cummins engine delivers on that front. Cummins engines are known for their durability and can withstand heavy-duty applications, ensuring that the forklift can handle frequent usage with ease. The engine's design includes rigorous testing, high-quality materials, and top-of-the-line manufacturing processes, which ensures optimum performance, even in the harshest environments. Furthermore, the engine is easy to maintain and offers reduced downtime for repairs or maintenance, meaning your equipment is always ready to perform when you need it.
Safety is a significant concern when operating heavy equipment, and the Cummins engine offers several safety features that make the Diesel Driven Forklift a more secure choice. The engine's control module is designed to protect it from overheating, overloading or other potentially hazardous situations. Additionally, the engine boasts a diagnostic system that provides real-time monitoring and alerts the operator of any potential issues, allowing for quick resolutions.
In conclusion, the diesel-driven forklift with an optional Cummins engine is an excellent choice for any warehouse or manufacturing industry. It offers several features that increase productivity, reduce downtime, and ensure operator safety.
Technical parameters
|
General |
Model |
FD60 |
|||
|
Power Type |
Diesel |
||||
|
Rated Capacity |
kg |
6000 |
|||
|
Load Centre |
mm |
600 |
|||
|
Characteristic&Dimension |
Lift Height |
mm |
3000 |
||
|
Fork Size |
L×W×T |
mm |
1220×150×60 |
||
|
Mast Tilt Angle |
F/R |
Deg |
6°/12° |
||
|
Fork Overhang (Wheel center to fork face) |
mm |
590 |
|||
|
Ground Clearance(Bottom of mast) |
mm |
200 |
|||
|
Overall Dimension |
Length to face of fork(Without fork) |
mm |
3440 |
||
|
Overall Width |
mm |
2010 |
|||
|
Mast Lowered Height |
mm |
2500 |
|||
|
Mast Extended Height(With backrest) |
mm |
4415 |
|||
|
Overhead Guard Height |
mm |
2430 |
|||
|
Turning Radius (outside) |
mm |
3250 |
|||
|
Performance |
Speed |
Travel (Full load) |
km/h |
30 |
|
|
Lifting (Full load) |
mm/s |
500 |
|||
|
Max.Gradeability |
% |
20 |
|||
|
Chassis |
Tyre |
Front |
mm |
8.25-15-14PR |
|
|
Rear |
mm |
8.25-15-14PR |
|||
|
Wheelbase |
mm |
2250 |
|||
|
Self weight |
kg |
8750 |
|||
|
Power&Transmission |
Battery |
Voltage/Capacity |
V/Ah |
(12/80) x 2 |
|
|
Engine |
Model |
6BG1-02 |
|||
|
Manufacture |
ISUZU |
||||
|
Rated output/r.p.m. |
kw |
82.4/2000 |
|||
|
Rated torque/r.p.m. |
N·m |
416/1600 |
|||
|
No.of Cylinder |
6 |
||||
|
Bore×Stroke |
mm |
105×125 |
|||
|
Displacement |
cc |
6494 |
|||
|
Fuel Tank Capacity |
L |
125 |
|||
|
Transmission |
Type |
Hydraulic |
|||
|
Stage |
FWD/RVS |
2/2 |
|||
