Introducing our flagship 3.5-ton electric forklift truck, a pinnacle of engineering designed to redefine efficiency and sustainability in material handling. Engineered with a cutting-edge 309V high-voltage platform powered by authentic CATL (Contemporary Amperex Technology Limited) batteries, this best electric forklift truck guarantees unmatched performance and reliability, ensuring uninterrupted operations even in the most demanding applications.
Boasting a rapid charging capability that promises 8 hours of comprehensive operation after just 30 minutes of charge, our electric powerhouse revolutionizes workflow dynamics. This feature dramatically reduces downtime, enhancing productivity and ensuring that your operations stay ahead of the curve.
At the heart of our design lies a state-of-the-art three-electric (battery, motor, and controller) thermal management system. This intelligent system meticulously regulates temperature, optimizing energy consumption, and prolonging component lifespan, thus ensuring consistent power output and reducing maintenance costs over time.
Embracing resilience, our forklift is meticulously crafted to conquer the extremes. Be it scorching heat, freezing cold, dusty environments, or the challenging altitude, our electric forklift truck operates unfazed, showcasing its true all-weather, all-environment prowess. It's a testament to our commitment to delivering solutions that excel in any condition, ensuring that no challenge stands in the way of getting the job done.
In summary, our 3.5-ton electric forklift truck exemplifies the perfect blend of power, efficiency, and adaptability. It's not just an electric forklift-it's the best electric forklift truck, designed to empower your operations with clean energy, superior performance, and unwavering reliability, pushing the boundaries of what's possible in the realm of material handling. Experience the future of sustainable logistics today.
attachment
OEM service
About LTMG
About LTMG
|
Model |
FB35 |
|
|
Rated Capacity |
kg |
3500 |
|
Load Centre |
mm |
500 |
|
Lift Height |
mm |
3000 |
|
Fork Size (L×W×T) |
mm |
1070×125×50 |
|
Mast Tilt Angle F/R (α°/β°) |
Deg |
6/12 |
|
Length to fork face of fork (Without fork) |
mm |
2615 |
|
Overall Width |
mm |
1230 |
|
Mast Lowered Height |
mm |
2115 |
|
Mast Extended Height (With backrest) |
mm |
4180 |
|
Overhead Guard Height |
mm |
2250 |
|
Turning Radius (outside) |
mm |
2350 |
|
Front Overhang (Wheel center to fork face) |
mm |
485 |
|
Tread (Front/Rear) |
mm |
1000/980 |
|
Ground Clearance (Bottom of mast) |
mm |
140 |
|
Wheelbase |
mm |
1700 |
|
Fork Spread (Min./Max) |
mm |
250/1100 |
|
Travel Speed |
km/h |
14 |
|
Lifting Speed (Full load) |
mm/s |
280 |
|
Max. Gradeability |
% |
15 |
|
Service Weight |
kg |
5350 |
|
Front Tire×2 |
28×9-15-12PR |
|
|
Rear Tire×2 |
18×7-8 |
|
|
Driven Motor |
kw |
15 |
|
Lift Motor |
kw |
12 |
|
Battery Standard |
V/Ah |
80/550 |
|
Controller Manufacturer |
CURTIS AC |
|
|
Operating Pressure for Attachment |
Mpa |
18 |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail;
