Products Description
Model | FB120 | |
Rated Capacity | kg | 12000 |
Load Centre | mm | 600 |
Lift Height | mm | 3000 |
Fork Size (L×W×T) | mm | 1220×175×85 |
Mast Tilt Angle F/R (α°/β°) | Deg | 6/10 |
Length to face of fork (Without fork) | mm | 4415 |
Overall Width | mm | 2250 |
Mast Lowered Height | mm | 2830 |
Mast Extended Height (With backrest) | mm | 4260 |
Overhead Guard Height | mm | 2640 |
Turning Radius (outside) | mm | 3850 |
Front Overhang (Wheel center to fork face) | mm | 845 |
Tread (Front/Rear) | mm | 1736/1754 |
Ground Clearance (Bottom of mast) | mm | 230 |
Wheelbase | mm | 2850 |
Fork Spread (Min./Max) | mm | 515/2055 |
Travel Speed | km/h | 14 |
Lifting Speed (Full load) | mm/s | 280 |
Max. Gradeability | % | 10 |
Service Weight | kg | 15800 |
Front Tire | 9.00-20 | |
Rear Tire | 8.25-20 | |
Driven Motor | kw | 14×2 |
Lift Motor | kw | 25×2 |
Battery Standard | V/Ah | 96/1250 |
Controller Manufacturer | CURTIS AC | |
Operating Pressure for Attachment | Mpa | 18 |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail;
Products Description
The 120-ton diesel forklift offers several significant advantages when operating in container yards or ports:
1. Powerful Performance: With a capacity of 120 tons, these heavy-duty diesel forklifts can effortlessly handle and transport overweight containers, optimizing the loading and unloading processes in port terminals and container depots. Their powerful diesel engines provide ample torque and speed to manage the heaviest loads.
2. Efficient Container Handling: Designed with long-reach booms and specialized attachments, these forklifts can stack and retrieve containers at considerable heights, maximizing space utilization in congested container yards. They can also maneuver in tight spaces, increasing the efficiency of operations.
3. Reliability in Tough Conditions: Diesel forklifts are built for rugged and continuous use, making them suitable for the demanding environment of container yards, where they may be exposed to extreme weather conditions, dust, and constant use.
4. Fuel Efficiency: Despite their massive size and power, modern diesel engines deliver fuel-efficient operation, which reduces operational costs and downtime spent on refueling.
5. Versatile Applications: The 120-ton diesel forklift can be configured with various attachments, allowing it to perform multiple functions such as lifting, stacking, and transporting containers, as well as intermodal handling.
6. Simplified Maintenance: Diesel engines are known for their durability and straightforward maintenance. Regular servicing keeps these machines running smoothly, minimizing unscheduled downtime.
7. Adherence to Regulations: These forklifts often comply with stringent emission standards, ensuring they can operate in ports that enforce environmental regulations.
In summary, the 120-ton diesel forklift brings unparalleled power, versatility, and reliability to container handling operations, boosting productivity and profitability in port logistics and container terminal management.
FAQ
Q: Can electric forklifts be used outdoors?
Q: What is the typical battery life for an electric forklift?
