Products Description
Introducing our premier 6-ton LPG forklift, a powerhouse designed to merge robust performance with enhanced ergonomics and safety, redefining the standards in gasoline-powered forklifts.
One of its standout features is the inclusion of a generously sized panoramic mirror, ensuring a comprehensive view that dramatically minimizes blind spots. This thoughtful design element significantly enhances traffic safety within busy warehouse environments, allowing operators to navigate with confidence and precision.
Comfort takes center stage with our adjustable seating arrangement. The seats boast an impressive adjustment range of up to 150mm, complemented by a compact steering wheel design, catering to operators of varying statures. This customization promotes prolonged operational comfort, reducing fatigue and enhancing overall efficiency.
Innovative engineering sees the tilt cylinder nestled neatly within the body of the forklift, paired with a foot brake suspended on a flattened plate layout. This configuration not only streamlines the aesthetics but also contributes to a smoother, more spacious driving experience, where every inch of the cabin is optimized for operator ease.
Our 6-ton LPG forklift embraces a short wheelbase design, complemented by a large turning axle, enabling sharp maneuverability. Both the front and rear wheels are fitted with sturdy solid tires as standard, further facilitating a reduction in the turning radius. This combination allows for agile navigation in confined spaces, enhancing productivity without compromising stability.
attachment
feedback from client
|
Model |
FG60 |
|||
|
Power Type |
LPG /Gasoline |
|||
|
Rated Capacity |
kg |
6000 |
||
|
Load Centre |
mm |
600 |
||
|
Lift Height |
mm |
3000 |
||
|
Fork Size |
L×W×T |
mm |
1220×150×60 |
|
|
Mast Tilt Angle |
F/R |
Deg |
6°/12° |
|
|
Fork Overhang (Wheel center to fork face) |
mm |
590 |
||
|
Ground Clearance(Bottom of mast) |
mm |
200 |
||
|
Overall Dimension |
Length to face of fork(Without fork) |
mm |
3440 |
|
|
Overall Width |
mm |
2010 |
||
|
Mast Lowered Height |
mm |
2500 |
||
|
Mast Extended Height(With backrest) |
mm |
4415 |
||
|
Overhead Guard Height |
mm |
2430 |
||
|
Turning Radius (outside) |
mm |
3250 |
||
|
Speed |
Travel (Full load) |
km/h |
30 |
|
|
Lifting (Full load) |
mm/s |
500 |
||
|
Max.Gradeability |
% |
20 |
||
|
Tyre |
Front |
mm |
8.25-15-14PR |
|
|
Rear |
mm |
8.25-15-14PR |
||
|
Wheelbase |
mm |
2250 |
||
|
Self weight |
kg |
8750 |
||
|
Battery |
Voltage/Capacity |
V/Ah |
12/120 |
|
|
Engine |
Model |
PSI4.3L |
||
|
Manufacture |
PSI |
|||
|
Rated output/r.p.m. |
kw |
76/2300 |
||
|
Rated torque/r.p.m. |
N·m |
324/1700 |
||
|
No.of Cylinder |
6 |
|||
|
Bore×Stroke |
mm |
101.6×88.4 |
||
|
Displacement |
cc |
4300 |
||
|
Fuel Tank Capacity |
L |
125 |
||
|
Transmission |
Type |
Hydraulic |
||
|
Stage |
FWD/RVS |
2/2 |
||
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail;
