The 25 Ton Diesel Operated Forklift has a 4-meter mast, which can lift and lower loads up to 25 tons. The mast is made of high-strength steel and has a full-length keyway to prevent rotation. The mast also has a hydraulic cushioning device to reduce the impact and vibration of the load
The 25 Ton Diesel Operated Forklift comes with a 2400mm fork, which can handle a variety of pallet sizes and shapes. The fork is made of chromium-manganese steel, which guarantees a high mechanical strength and durability. The fork also has a fully rounded toe section for easy entry into and out of loads or pallets.
The Forklift also has a side-shift adjustable fork, which allows you to shift the load from side to side for faster and more accurate lifting and placement. The side-shift adjustable fork eliminates the need to move the whole forklift, saving time and fuel. The side-shift adjustable fork also reduces the damage to pallets and products
The Forklift has an enclosed cab, which protects the operator from the outside elements, such as rain, dust, or noise. The enclosed cab also provides a comfortable and ergonomic working environment for the operator. The enclosed cab has a clear visibility, a spacious interior, a ventilation system, and a dashboard with all the necessary indicators and controls
Technical Specification
| Model | FD250 | ||
| Features | Rated Load | Kg | 25000 |
| Load Center | mm | 1220 | |
| Wheelbase | mm | 4400 | |
| Weight | Weight | kg | 33500 |
| Chassis | Tire Specs:Front | 14.00-24 | |
| Tire Specs:Rear | 14.00-24 | ||
| Tires Qty,front/rear(X-dreve wheels) | 4/2 | ||
| Wheel tread:Front | mm | 2220 | |
| Wheel tread:Rear | mm | 2300 | |
| Dimensions | Mast/carriage tilt angle(front/rear) | Degree(°) | 6/12 |
| Mast height(fork lowering) | mm | 3970 | |
| Mast lifting height | mm | 4000 | |
| Max.height | mm | 5940 | |
| height to head guard(height to cab) | mm | 3440 | |
| Overall height(with forks) | mm | 8950 | |
| Fork front verticaal sueface to the rear end of the vehicle | mm | 6550 | |
| Overall width | mm | 3060 | |
| Fork dimension | mm | 2400*300*100 | |
| Fork carriage width | mm | 2800 | |
| Mast min ground(with load) | mm | 350 | |
| Wheelbase center min ground(with load) | mm | 420 | |
| Min.turning Radius | mm | 6160 | |
| Travel speed(with load/without load) | km/h | 25/30 | |
| Performance | lifting speed(with load/without load) | mm/s | 260/270 |
| tractionn | KN | 160 | |
| gradeability(with load/without load) | % | 20/22 | |
| Driving brake | Hydraulic clamp disvc | ||
| Engine | Engine brand | Dongfeng cummins | |
| Engine model | 6CTA8.3-C215 | ||
| Rated Output | 160(Kw) | ||
| Cylinder No | 6 | ||
| Others | Transmission gears(Front/rear) | 2/1 |
certification
advantage
optional attachment
FAQ
Q: What are the benefits of the enclosed cab in the 25 ton diesel forklift?
Q: How does the electro-hydraulic operation system improve the efficiency and safety of the 25 ton diesel forklift?
Q: What are the warranty and after-sales service options for the 25 ton diesel forklift?
Q: What are the advantages of the 4-meter mast, 2400 mm fork, and side-shift distance fork in the 25 ton diesel forklift?
