Products show
Products parameters
| Model | FD30 | FD35 | FD38 | |
| Rated lifting load | kg | 3000 | 3500 | 3800 |
| Load center distance | mm | 500 | ||
| Free lifting height | mm | 160 | ||
| overall length (Withfork/Withoutfork) | mm | 3752/2682 | 3763/2693 | 3963/2893 |
| Width | mm | 1225 | ||
| Overhead guard height | mm | 2090 | ||
| Wheelbase | mm | 1700 | ||
| Minimum ground clearance | mm | 135 | ||
| Mast tilt angle (front/rear) | % | 6° /12° | ||
| Tire no. (before) | 28*9-15-14PR | |||
| Tire no. (after) | 6.5-10-1OPR | |||
| Minimum turning radius (outer side) | mm | 2400 | 2420 | 2710 |
| Minimum right angle aisle width | mm | 4260 | 4260 | 4720 |
| Fork size | mm | 1070*125*45 | 1070*125*50 | 1070*150*50 |
| maximum working speed(Full-load/No-load) | km/h | 18/19 | 19/19 | |
| maximum lifting speed(Full-load/No-load) | mm/s | 440/480 | 330/370 | 340/380 |
| maximum gradeability(Full-load/No-load) | % | 15/20 | ||
| Forklift weight | kg | 4250 | 4500 | 4800 |
| Engine model | Xinchai C490 | |||
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail;
Our Advantages
1. "Streamlined Pallet Manipulation" - Elevate your warehouse efficiency with our Box Tipper Forklift, expertly designed to smoothly tip and rotate pallets with minimal effort, streamlining your material flow.
2. "Compact and Versatile" - Our Box Tipper's compact build fits seamlessly into your warehouse operations, offering unmatched versatility for various pallet sizes and layouts without compromising on space.
3. "Durable and Dependable" - Constructed with top-grade materials, our Box Tipper Forklift stands up to the test of time, delivering consistent performance in the most rigorous warehouse environments.
4. "Tailored Functionality" - Recognizing the diverse needs of businesses, our Box Tipper Forklift is available with a range of attachments, ensuring it can handle a multitude of pallet types and sizes with ease.
5. "Safety-First Operation" - We prioritize safety with our Box Tipper Forklift, featuring advanced safety features that provide a secure and controlled operation, safeguarding both your operators and your cargo.
