Products Description
Introducing our state-of-the-art FG Series, a line of 5-ton LPG gasoline engine forklifts meticulously designed to redefine comfort, ease of operation, and efficiency in material handling. These robust machines embody the perfect harmony of power and precision, ensuring not only superior performance but also an enhanced user experience that directly contributes to elevated productivity levels.
At the core of our design philosophy for the FG Series lies the commitment to operator comfort. Recognizing that a comfortable work environment is key to maximizing output, we've integrated advanced features like significantly reduced vibration levels, a sophisticated compound engine damper, and a fully floating seat with an ergonomically designed cabin. These innovations work in tandem to minimize operator fatigue, allowing users to focus on the task at hand for longer durations without compromise.
Stepping into the realm of user-friendly accessibility, we've expanded the footwell area to offer extra room, dramatically reducing operator exhaustion over extended shifts. Coupled with a newly designed wide-open, non-slip entry step, getting in and out of the forklift becomes a breeze, ensuring safety and convenience at all times. This thoughtful design aspect further bolsters overall operational efficiency by minimizing downtime and enhancing workflow fluidity.
Embracing technological advancements, we present the optional Electro-hydraulic Proportional Control System, a game-changer for those seeking the pinnacle of load handling sensitivity and precision. This system empowers operators with unparalleled control, enabling them to maneuver even the most delicate loads with finesse. Complemented by intuitive levers that consolidate all load-handling operations into effortless gestures, the FG Series elevates the standard of operational ease. An ergonomic armrest is also thoughtfully incorporated to provide additional support, thereby mitigating fatigue during prolonged use.
Going beyond conventional features, our FG Series forklifts incorporate a dual softening mechanism – the Soft Landing System complemented by the Soft Lifting System. This innovative approach, applied to the front lifting cylinders of both triplex mast and full-free duplex mast configurations, drastically diminishes noise and mast shocks. The result is a smoother, quieter operation that not only fosters a more pleasant working environment but also safeguards the integrity of goods being handled and extends the lifespan of the equipment.


In summary, the 5-ton LPG gasoline engine forklifts of the FG Series represent the pinnacle of modern forklift technology, where operator comfort, precision control, and operational efficiency converge. By prioritizing user-centric design elements, advanced control systems, and innovative lifting mechanisms, these machines stand as a testament to our dedication to enhancing every aspect of material handling. Experience firsthand how the FG Series transforms your warehouse or industrial setting, redefining productivity and operator satisfaction in the process.
attachment
feedback from client
Model |
FG50 |
|||
Power Type |
LPG |
|||
Rated Capacity |
kg |
5000 |
||
Load Centre |
mm |
600 |
||
Lift Height |
mm |
3000 |
||
Fork Size |
L×W×T |
mm |
1220×150×60 |
|
Mast Tilt Angle |
F/R |
Deg |
6°/12° |
|
Fork Overhang (Wheel center to fork face) |
mm |
590 |
||
Ground Clearance(Bottom of mast) |
mm |
200 |
||
Overall Dimension |
Length to face of fork(Without fork) |
mm |
3440 |
|
Overall Width |
mm |
2010 |
||
Mast Lowered Height |
mm |
2500 |
||
Mast Extended Height(With backrest) |
mm |
4415 |
||
Overhead Guard Height |
mm |
2430 |
||
Turning Radius (outside) |
mm |
3250 |
||
Speed |
Travel (Full load) |
km/h |
30 |
|
Lifting (Full load) |
mm/s |
500 |
||
Max.Gradeability |
% |
20 |
||
Tyre |
Front |
mm |
8.25-15-14PR |
|
Rear |
mm |
8.25-15-14PR |
||
Wheelbase |
mm |
2250 |
||
Self weight |
kg |
8150 |
||
Battery |
Voltage/Capacity |
V/Ah |
12/120 |
|
Engine |
Model |
PSI4.3L |
||
Manufacture |
PSI |
|||
Rated output/r.p.m. |
kw |
76/2300 |
||
Rated torque/r.p.m. |
N·m |
324/1700 |
||
No.of Cylinder |
6 |
|||
Bore×Stroke |
mm |
101.6×88.4 |
||
Displacement |
cc |
4300 |
||
Fuel Tank Capacity |
L |
125 |
||
Transmission |
Type |
Hydraulic |
||
Stage |
FWD/RVS |
2/2 |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail;
