Product Advantsges
1.Wide view mast design, ensure the driver has an excellent view, which makes loading and unloading operations more secure and efficient;
2.Load sensing priority steering hydraulic system design, flexible steering, mast lift speed increased by 20%;
3.All accessories like engine, gear box are support by domestic and world famous brand, high quality, reliable after-sales;
4.The overhead guard adopts the high strength steel sheet to press molding, providing more sophisticated security for the driver, it can also prevent wind and rain.
Certifications of LTMG
1.CE marking (Conformité Européene) - CE marking is a product safety certification mark practiced in EU countries. Any goods sold in the European Economic Area (EEA) that fall within the scope of control of the CE Directive must be labeled with the CE mark, indicating that the product complies with the relevant EU regulations and standards, and meets the basic requirements of health, safety, environmental protection and consumer protection. In the field of industrial equipment, such as forklift trucks, bulldozers, etc., CE marking is the passport to enter the EU market.
2.CO Certificate (Certificate of Origin) - CO Certificate, i.e. Certificate of Origin, is a document issued by the official organization of the exporting country to prove the place of production of the goods. It is an important document in international trade and may be required by importers to enjoy preferential tariff treatment or to prove the origin of the goods in order to comply with the trade regulations of the importing country.
3.ISO Certificate (International Organization for Standardization) - The ISO certificate represents that the enterprise has obtained the relevant management system certificates developed by the International Organization for Standardization, such as ISO 9001 Quality Management System Certification, ISO 14001 Environmental Management System Certification ISO 45001 Occupational Health and Safety Management System Certification.
Similar products
1. Telescopic Forklift (Telescopic Handler): - Telescopic Forklift, also known as Telescopic Forklift, is a special vehicle that combines the telescopic boom structure of automobile cranes and the functions of traditional forklifts. The most notable feature of this type of forklift is that it has a telescopic boom, which can be equipped with forks or other work attachments at the top of the boom.
2. Sideloader: - The forks of a sideloader are located on the side of the vehicle rather than the front. This design allows the vehicle to operate in tighter spaces, especially where warehouse aisle widths are limited. Side-by-side forklifts are particularly suitable for pallet-intensive storage and can be easily accessed from the side of the racking, which greatly improves the utilization of warehouse space.
3. Electric Forklift (Electric Forklift): - The power source of electric forklift is battery-powered electric motor. Compared with fuel forklift, electric forklift has the advantages of zero emission, low noise, low vibration, easy maintenance, etc. It is especially suitable for indoor warehouses, food processing, pharmaceutical manufacturing and other places with high requirements for environmental cleanliness.
4. LPG Forklift (Liquefied Petroleum Gas Forklift): - LPG forklift is an internal combustion forklift that uses liquefied petroleum gas (LPG) as its fuel, and its engine burns compressed LPG. Compared with gasoline or diesel forklifts, LPG forklifts have relatively less exhaust emissions and less pollution, and LPG is relatively easy to obtain and store at a moderate cost.
Forklift parametersTechnical Parameter 技术参数 |
||
| Model | FD300 | |
| Rated Load | Q(Kg) | 300000 |
| Load Center | c(mm) | 1220 |
| Wheelbase | y(mm) | 4400 |
| Weight | kg | 33500 |
| Tire Specs:Front | 14.00-24 | |
| Tire Specs:Rear | 14.00-24 | |
| Tires Qty,front/rear(X-dreve wheels) | 4/2 | |
| Wheel tread:Front | b3(mm) | 2220 |
| Wheel tread:Rear | b4(mm) | 2300 |
| Mast/carriage tilt angle(front/rear) | Degree(°) | 6/12 |
| Mast height(fork lowering) | h1(mm) | 3970 |
| Mast lifting height | h2(mm) | 3000 |
| Max.height | h3(mm) | 5940 |
| height to head guard(height to cab) | h4(mm) | 3440 |
| Overall height(with forks) | L3(mm) | 8950 |
| Fork front verticaal sueface to the rear end of the vehicle | L2(mm) | 6550 |
| Overall width | b1(mm) | 3060 |
| Fork dimension | (mm) | 2400*300*100 |
| Fork carriage width | b2(mm) | 2800 |
| Mast min ground(with load) | m1(mm) | 350 |
| Wheelbase center min ground(with load) | m2(mm) | 420 |
| Min.turning Radius | Wa(mm) | 6160 |
| Travel speed(with load/without load) | km/h | 25/30 |
| Max.lifting speed(with load/without load) | mm/s | 260/270 |
| tractionn | KN | 160 |
| gradeability(with load/without load) | % | 20/22 |
| Driving brake | Hydraulic clamp disvc 液压夹具 | |
| Engine brand/model | Optional one | WeiChai Engine |
| WD10G220E | ||
| Optional two | Dongfeng cummins | |
| Rated Output | 162(Kw) | |
| Cylinder No | 6 | |
| Transmission gears(Front/rear) | 2/1 | |
With technological innovation, our product configuration and parameters will continue to change without notice;
If there is any doubt, the specific confirmation of our international trade sales shall prevail;
